State of the art design delivers special standard features:

Polyurethane Drive Train

• Eliminates the need to load coil prior to transportation (less material waste)
• Roll form 24-gauge steel.
• Eliminates slippage from cold weather and condensation.

.002 Chrome Plated Steel Forming Rollers

• Roll forms all standard metals with minimal or no adjustment.
• Free-floating forming rollers produce less pressure and allow for more product uniformity.

Electrical and Control System

• Push button control safety wiring
• Entrance and exit control selector switch jog run.
• 3/4 HP, 110 Volt, Single Phase Motor, 13.6 Ampere

Structural Steel Frame

• Welded steel frame

Modular Turn style Upright System

Specifications:

Power:

3/4 HP, 110 V. Single Phase 13.6 amperes totally enclosed fan cooled (T.E.F.C) motor.

Dimensions:

Length - 122"
Height - 48"
Width - 24"

Weight:

Approximately 1300 lbs.

Drive:

Powered polyurethane drive rollers via chains and sprockets.

Shear:

Front pull guillotine

Speed:

Approximately 35 feet per minute.

Controls:

Push button entry and exit end manual controls with "jog" feature

Recommended Materials:

15" wide

New easy-adjust entrance guides

Front pull guillotine

Options:

• Machine mount cradles
• Fixed upright system
• Additional run out support stands
• CE Certified Wiring

• Additional turn styles
• Additional spools
• Alcoa style hook

Pricing:

IRON MAN 6" - Includes double turn style upright, two spools, front pull guillotine, push button controls and two run out stands

$9,700.00

Base Machine

$7,872.00

Alcoa Style Hook

$1,250.00

Front Pull Guillotine Push Button Controls

$504.00

Adjustable Width Single Spool

$196.00

Cradle

$456.00

Run-out Stands

$98.00

Coil Transfer Bar Set

$160.00

Single Turn style Upright

$276.00

$276.00

$820.00

Machine Mount Cradle

$486.00
